| Series | Fxx92 |
| Package diameter | |
| Operating Direction | Vertical |
| Bushing material | |
| Number of Gangs | |
| Power-linear | 0.025W |
| Power-audio | 0.0125W |
| Life cycle | 10K |
| Switch Option | |
| Detent Option | Y |
| Mounting | |
| Element | 1-2 |
| Temperature ppm/℃ | |
| Tolerance | |
| Pulse | |
| Shaft material | |
| Life cycle | |
| Operating type | |
| Power rating | |
| Travel(mm) | 20/30 |
| Lever length | 9.5 |
| Turns | |
| Specification | Document download |
Introdution
1.Flux builed-up prevention is taken through inserting molding around the resistor with resin.
2.Improve operational feel, snap and mounting strength.
3.Available with center tap and center detent.
| Electrical characteristics | |
| Total Resistance | 1KΩ~1MΩ |
| Total Resistance Tolerance | 500Ω＜R＜1MΩ:± 20% :R＜500Ω or R＞1MΩ:±30% |
| Resistance Taper | A, B, W |
| Withstand Voltage | 1 minute at AC 250V |
| Insulated Resistance | More than 100MΩat DC 250V |
| Sliding Noise | Less than 100mV |
| Residual Resistance | Term.1~2: Less than 30Ω:Term.2~3: Less than 50Ω |
| Gang Error (Dual Unit) | ± 2dB at the point 50% travel |
| Max. Operation Voltage | AC 50V/DC 10V |
| Rated Power | 0.025W |
| Mechanical characteristics | |
| Slide Travel | 20mm, 30mm |
| Operating Force | 10gf~100gf |
| Stopper Strength | 3.0Kgf (from the bas Level to a point of 2mm) |
| Click torque (Only Center Click) | 30~150gf |
| Level Push-Pull Strength | 3.0Kgf Min at 10Sec. |
| Level Wobble | 2 (2XL)/20mm Max. (L: Level length both sides) |
| Durability | |
| Sliding life | 50,000 Cycles Min. |
